Teknik Özellikler |
Units |
XH1809 |
XH1316 |
XH1320 |
XH1330 |
XH1625 |
XH2416*2.5 |
XH2416-3 |
XH2416*4 |
XH2425*4 |
XH2425*5 |
XH2425-6 |
XH2425-8 |
|
Worktable size |
mm |
1600x800 |
1300x1600 |
1300x2000 |
1300x3000 |
1600x2500 |
2500x1600 |
3000x1600 |
4000x1600 |
4000x2500 |
5000x2500 |
6000x2500 |
8000x2500 |
|
X axis (worktable move front and back) |
mm |
1800 |
1600 |
2000 |
3000 |
3000 |
2700 |
3200 |
4200 |
4200 |
5200 |
6200 |
8200 |
|
Y axis (slide move left and right) |
mm |
900 |
1500 |
1500 |
1500 |
1500 |
2200 |
2200 |
2200 |
3400 |
3400 |
3400 |
3400 |
|
Z axis(spindle move up and down) |
mm |
750 |
500/750 |
500/750 |
500/750 |
500/750 |
1000 |
1000 |
1000 |
1200 |
1200 |
1200 |
1200 |
|
Distance between two column |
mm |
1800 |
1600 |
1600 |
1600 |
1800 |
2100 |
2200 |
2500 |
3200 |
3200 |
3200 |
3200 |
|
Spindle speed range and driving method |
mm |
/ |
/ |
/ |
/ |
/ |
6000 belt driving |
6000 belt driving |
6000 belt driving |
6000 belt driving |
6000 belt driving |
6000 belt driving |
6000 belt driving |
|
Distance from spindle nose to table surface |
|
150-900 |
150-650/900 |
150-650/900 |
150-650/900 |
150-650/900 |
200-1200 |
200-1200 |
200-1200 |
250-1250 |
250-1250 |
250-1250 |
250-1250 |
|
Spindle taper |
mm |
BT50 |
BT50 |
BT50 |
BT50 |
BT50 |
BT50 |
BT50 |
BT50 |
BT50 |
BT50 |
BT50 |
BT50 |
|
Spindle diameter |
mm/min |
190 |
155 |
155 |
155 |
155 |
190 |
190 |
190 |
190 |
190 |
190 |
190 |
|
Rapid traverse speed – X axis |
mm/min |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
|
Rapid traverse speed – Y axis |
mm/min |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
12000 |
|
Rapid traverse speed – Z axis |
mm/min |
10000 |
10000 |
10000 |
10000 |
10000 |
10000 |
10000 |
10000 |
10000 |
10000 |
10000 |
10000 |
|
Feed rate ( X / Y / Z axes) |
mm/min |
1-8000 |
1-8000 |
1-8000 |
1-8000 |
1-8000 |
1-8000 |
1-8000 |
1-8000 |
1-8000 |
1-8000 |
1-8000 |
1-8000 |
|
Number of tool magazine--opt. |
|
24 /opt.-32 |
24 /opt.-32 |
24 /opt.-32 |
24 /opt.-32 |
24 /opt.-32 |
24/opt.-32 |
24/opt.-32 |
24/opt.-32 |
24/opt.-32 |
24/opt.-32 |
24/opt.-32 |
24/opt.-32 |
|
Tool magazine type |
|
Disc type |
Disc type |
Disc type |
Disc type |
Disc type |
Disc type |
Disc type |
Disc type |
Disc type |
Disc type |
Disc type |
Disc type |
|
Controller |
|
FANUC/Siemens |
FANUC/Siemens |
FANUC/Siemens |
FANUC/Siemens |
FANUC/Siemens |
FANUC/Siemens |
FANUC/Siemens |
FANUC/Siemens |
FANUC/Siemens |
FANUC/Siemens |
FANUC/Siemens |
FANUC/Siemens |
|
X/Y/Z axis ball screw diameter |
mm |
/ |
/ |
/ |
/ |
/ |
80/50/50 |
80/50/50 |
80/50/50 |
80/50/50 |
80/50/50 |
80/50/50 |
80/50/50 |
|
XYZ axis linear guideway width |
mm |
/ |
/ |
/ |
/ |
/ |
55/55/55 |
55/55/55 |
55/55/55 |
55/55/55 |
55/55/55 |
55/55/55 |
55/55/55 |
|
Spindle motor |
kw |
15 |
11 |
11 |
11 |
11 |
15/18.5 |
15/18.5 |
15/18.5 |
22 |
22 |
22 |
22 |
|
Positioning accuracy(JIS standard) |
mm |
±0.005 /300 |
±0.005 /300 |
±0.005 /300 |
±0.005 /300 |
±0.005 /300 |
±0.005 /300 |
±0.005 /300 |
±0.005 /300 |
±0.005 /300 |
±0.005 /300 |
±0.005 /300 |
±0.005 /300 |
|
Repeatability Positioning accuracy(JIS standard) |
mm |
±0.003 /1000 |
±0.003 /1000 |
±0.003 /1000 |
±0.003 /1000 |
±0.003 /1000 |
±0.003 /1000 |
±0.003 /1000 |
±0.003 /1000 |
±0.003 /1000 |
±0.003 /1000 |
±0.003 /1000 |
±0.003 /1000 |
|
Worktable loading capacity |
T |
2 |
1.6 |
2.2 |
2.4 |
3 |
6 |
8 |
10 |
14 |
22 |
30 |
38 |
|
Weight |
T |
17.5 |
13/13.5 |
14/14.5 |
17.5/18 |
19 |
27 |
29 |
33 |
34 |
50 |
67 |
85 |
